COMBI Refco

Condensate Pump COMBI Refco 3004146

The Refco Combi condensate pump is a completely newly developed condensate pump, specifically manufactured for use in split air conditioning systems. It has many individually adjustable functions that are unique on the global market. The Refco Combi condensate pump is designed for high pumping capacity and is suitable for systems from 6,000 BTU/h (1.75kW) up to 120,000 BTU/h (35kW).

General Features:

• max. suction height: 3 m
• max. discharge head: 20 m, up to 42 liters / hr.
• Power supply: 230 V AC, 50/60 Hz, 12 W
• Sound level: 19 dB (A)
• Dimensions: H 52 mm x W 107 mm x D 38 mm

Subject to technical changes and errors. The digital water sensor, universal voltage range, and individually configurable flow rate are features that allow installers and wholesalers to stock only one product that meets all requirements.

The device has a USB port, which allows access to the pump's operating history, greatly simplifying diagnostics. Manual configuration during installation optimizes water flow and noise levels. The pump is equipped with two DIP switches that allow four options for setting the power level.

Please note: New connection cables are supplied, as these have changed from the previous model and must therefore be replaced when replacing the pump.
