DML165S

Filter Drier DML 165S / 023Z4581 Danfoss

Filter Drier DML165S / 023Z4581 Danfoss 5/8" / 16 mm Solder ODF, Eliminator filter drier with copper-plated steel solder connection, 100% 3A molecular sieve, optimized for HFC refrigerants and POE or PAG oils.

Technical data

• thermally stable up to 120°C
• max. allowable operating pressure: 46 bar
• temperature range: -40 to +70°C
• available with flare or solder connections (copper-coated steel connections)
• any installation position with flow in arrow direction
• suitable for flammable refrigerants (DML 032s to DML 607s)
• Connection: 16 mm 5/8" ODF
• Length: 160 mm
• Solid insert surface area: 220 cm²
• Solid insert volume: 234 cm³
• Drying capacity refrigerant R134a: 24°C: 27.7g, 52°C: 26.2g
• Drying capacity refrigerant R404A: 24°C: 29.8g, 52°C: 28.3g
• Drying capacity refrigerant R507A: 24°C: 30.4g, 52°C: 28.0g
• Drying capacity refrigerant R407C: 24°C: 27.8g, 52°C: 25.7g
• Drying capacity refrigerant R410A: 24°C: 25.3g, 52°C: 23.3g
• Liquid capacity: R134a: 44.64kW, R404A: 36.59kW, R507A: 35.59kW, R407C: 50.16kW; R410A: 54.83kW
