Compressor NEK6170Z by Embraco Nidec
Hermetic reciprocating compressor NEK6170Z for high-pressure applications from the NE series by Embraco Nidec. Compressors in this series feature a fixed speed and two efficiencies, specifically designed for use in commercial refrigeration, offering robustness and reliability for food retail and food service. If relevant: Replaces model NE5170Z by Embraco Aspera.
The exact performance data can be found in the technical data sheet.
General features:
- Motor type: CSIR
- Refrigerant: R134a
- Mains voltage: 220-240V/1/50Hz
- Displacement: 8.39 cm³
- Oil charge: POE 22, 350 ml
- Expansion device: Capillary tube or valve
- Suction connection: 8.1 mm
- Discharge connection: 6.1 mm
- Dimensions (LxWxH): 199 x 162 x 188.4mm
- high product quality
- high equipment and system robustness
- low energy consumption
