Compressor NEK2134U by Embraco Nidec
Hermetic reciprocating compressor NEK2134U for low-pressure applications from the NE series by Embraco Nidec. Compressors of this series feature a fixed speed and two efficiency levels, specially designed for use in commercial refrigeration, offering robustness and reliability for food retail and food service. Replaces the EMTE2134U model from Embraco Aspera.
The exact performance data can be found in the technical data sheet.
General features:
- Motor type: CSIR
- Refrigerant: R290
- Mains voltage: 220-240V/1/50Hz
- Displacement: 9.99 cm³
- Oil charge: POE 22, 350 ml
- Expansion device: Capillary tube or expansion valve
- Suction connection: 8.1 mm
- Discharge connection: 6.1 mm
- Dimensions (LxWxH): 199 x 162 x 201mm
- high product quality
- high equipment and system robustness
- low energy consumption
