Compressor GLY12RA /GP12TB Cubigel Huayi

Fully hermetic compressor GLY12RA from Cubigel Huayi for high pressure applications. Replaces models GL11TB and GP12TB.

high product quality

high equipment and system robustness

low energy consumption

excl. VAT incl. VAT

139,90 € 166,48 € incl. VAT

~~169,00 € excl. VAT~~ ~~201,11 € incl. VAT~~ 139,90 € 169,00 € excl. VAT 166,48 € 201,11 € incl. VAT 169,00 € 201,11 €

Sale Sold out

Available immediately

1–3 working days

zzgl. Versandkosten

ArtNr 9201015 Hersteller Cubigel / Huayi Datenblatt

12 months material warranty
Purchase on account
14-day return policy

View full details

Product description

Compressor GLY12RA Cubigel

Hermetic compressor GLY12RA for the high-pressure range from Cubigel Huayi. Compressors of this series are characterized by their compact design, increased displacement, and high efficiency. Replaces models GL11TB and GP12TB.

The exact performance data can be found in the technical data sheet.

General features:

Motor type: CSIR
Refrigerant: R134a
Mains voltage: 200-220/220-230V/1/50/60Hz
Displacement: 10.70 cm³
Oil charge: ISO VG 32 Ester, 0.5L
Max. operating current: 4.20 A
Suction connection: 8.1 mm
Discharge connection: 6.5 mm
Injection: Capillary tube / Expansion valve
Dimensions (LxWxH): 192 x 162 x 198 mm

This item is suitable, among others, for devices from Alpeninox, Angelo-Po, Electrolux, Franstal, Metro-France, Nordton, OEM, OLIS, Polaris, Rieber, SAGI, Zanussi Professional, Zoppas.
